System on Module IoT Development Kits

$129.00$299.00

Embedded IoT Dev Kits with everything you need to create custom devices and applications from your Mac or Windows PC!

NetBurner System on Module (SOM) Development Kits are available to customize any aspect of operation including web pages, data filtering, or network applications. The kits include all the hardware and software you need to build your embedded product or automation solution. Compare specs for our full range of SOM Development Kit in tab below. Click on a specific product to view the individual product page.

$129.00

In Stock

$149.00

In Stock

$169.00

In Stock

$149.00

In Stock

$129.00

In Stock

$299.00

In Stock

$129.00

In Stock

Description

Choosing the right IoT Development Kit is no joke for serious projects. Find out why developers love working with NetBurner Embedded Dev Kits.

Your success is our success which is why NetBurner does everything possible to support the design and commercialization of cutting edge and reliable automation and IoT products and solutions. Our robust and easy to use development kits accelerate embedded development into scalable product and soluitions. With NetBurner, developers can focus on the core of their application and leave it to us to do the embedded heavy-lifting.

1. Included IoT Development Software

Eclipse-Based IDE

NBEclipse is a plug-in to the Eclipse IDE and provides a great environment to manage projects, edit code, debug, and download your application to NetBurner devices.

Example Source Code

Get hands-on familiarity with the NetBurner embedded platform by studying, building, and modifying the included source code examples. Each example consists of buildable and executable source code that illustrates how to accomplish one or more tasks.

Software Libraries

ANSI C/C++ compiler and linker (GNU Based), TCP/IP stack, Web server, E-mail protocols, RTOS, Flash file system, and more.

Security and Optional Software Modules

Embedded SSL/TLS & SSH Security Suite, SNMP V1 (optional Module License Version)

2. Hardware

Development Boards

Each SOM dev kit comes with the industrially-rated embedded system on module platform hardware. We also include a development carrier board which makes prototyping fast and easy. Interact with a NetBurner dev kits by loading examples that read and control integrated dip switches or LEDs in response to incoming data. NetBurner even provides schematics for development boards so that you can easily use them in your own designs and get deployed faster.

Power and data

Now you can communicate with processor UARTs from your Mac or Windows PC via USB. The on-board USB port also enables you to power the development board. Or use a wall powered barrel jack with +7 to +24 VDC supply of your choosing (or add one while shopping).

Flash card storage

The FAT12/16/32 flash file system gives developers the flexibility to store and exchange data through flash cards. NetBurner provides a standard API, complete C-based source code, drivers, and ample examples to get started.

3. Firmware

Simple firmware updates

Perform updates remotely. Update your hardware over 10/100 Ethernet or its serial port.

RTOS

Robust Real-Time Operating System (RTOS) optimized for high-speed encrypted networking, task management and IO. With NetBurner you get an RTOS that we stand behind and fully support.

4. Technical Support

E-Mail and Online Support Portal

All dev kits come with a limited time support package. Our prompt email support provides excellent results and works as follows: your email question is received by support personnel with a wide range of abilities. The individual best suited to answer the question will assume responsibility to answer your question. This method avoids tiered approach of forcing you to go through many people before finding the right person to help.

Documentation and Learn Tutorials

Getting started guides, manuals, and application notes can help you load your first application code image in minutes. Our Learn Blog features detailed hands-on tutorials with NetBurner embedded development kits, popular sensors, cloud services, and protocols.

Support Forum

The NetBurner forum is great to discuss any hardware or software issues with developers like you. It has been a great place for developers in the NetBurner community to share new ideas and to communicate unique implementations of the product.

5. Quality and Reliability

All of our products are made and checked for quality in the USA, rated for industrial operating temperatures, and are RoHS compliant. We stand by the quality and reliability of our products, include our Embedded IoT Development Kits, with our 1 year warranty and expert support.



Note: A development kit or software upgrade is required for each NetBurner platform type. The purpose of development kit boards is to demonstrate the features and functions of our module products. Development kit boards should not be designed into your final product as they continuously change as new features are added to the module product line. We are willing to provide the design information to you if you wish to manufacture a particular development board revision on your own.

Comparison Table

Part NumberCreates Applications for the Listed PlatformsTCP/IP StackSSL/TLS and SSHWireless OptionIDE Graphical DebuggerLifecycle
NEW! NNDK-SOMRT1061-KITSOMRT1061 200IR VersionStandard Network PlatformLatest
NNDK-MODM7AE70LC-KITMODM7AE70 100 & 200 VersionStandard Network PlatformLatest
NNDK-MOD54415LC-KITMOD54415 100 & 200 VersionStandard Network PlatformLatest
NNDK-MOD54417LC-KITMOD54417 100 & 200 VersionStandard Network PlatformLatest
NNDK-NANO54415-KITNANO54415 200 VersionStandard Network PlatformLatest
NNDK-MOD5234-KITMOD5234 100 & 200 VersionStandard Network PlatformMature
NNDK-MOD5234LC-KITMOD5234 100 & 200 VersionStandard Network PlatformMature
NNDK-MOD5270-KITMOD5270 100 & 200 VersionStandard Network PlatformMature
NNDK-MOD5270LC-KITMOD5270 100 & 200 VersionStandard Network PlatformMature
NNDK-MOD5213-KITMOD5213 100 VersionEmbedded Platform (non-network)Mature

More on Dev Kits

Embedded Ethernet Development Kit

Desktop Software

Powerful Hardware and Software that Makes Building Applications Easier

In addition to a core module, board level product development kits include a development board, software and technical support.

What makes NetBurner development kits different?

  • Every component including the hardware, software and developer tools is designed by NetBurner to work together seamlessly.
  • All development kits include world-class technical support.
  • Create and deploy applications from your Mac OS X 10.5+ or Windows XP/Vista/7 PC .
  • Get hands-on familiarity with the NetBurner platform by studying, building, and modifying ample source code examples.
  • Device applications can be written in C/C++ (or assembly language).
  • Includes Eclipse based IDE with graphical debugger. If you prefer using the command line, we include several source code examples with makefiles.
  • Includes royalty-free TCP/IP Stack, web server, Real-time OS (RTOS), and more. Although our software stack has a small memory footprint, you can include only what you need to free up additional memory or processing power.

To learn more about the development board that is included with this kit or learn about the standard development kit features and software, please click on the buttons below.
