i.MX RT1061 Embedded IoT Development Kit SOMRT1061

SOMRT1061 200 IR system-on-module breakout board mounted to a fully featured development board with RS232, Ethernet, USB, MicroSD, and power connectors

$129.00

Launch your product with our new i.MX RT1061 ARM®-Powered embedded IoT development kit! It includes all the hardware, software and development tools you need to create a network product:

  • Our SOMRT1061 ARM® platform hardware based on the NXP i.MX RT1061, in a 1″ (25.4mm) square footprint
  • Dual 10/100 Ethernet
  • RTOS, Network Stack including security TLS/SSH/HTTPS, and select peripheral drivers
  • GCC compiler and debugger
  • Development environments including Eclipse, command line, and easy integration into other tools like VSCode
  • Analog, digital and serial interfaces

Also see more information on our development kits and suite.

In Stock

SKU: NNDK-SOMRT1061-KIT Category: Tags: , , ,

Description

Robust, Scalable and Easy to Use Embedded IoT Development Kits

This NetBurner embedded development kit features the i.MX RT1061 ARM® Cortex® M7 System-on-Module (SOM) and is an IoT device containing everything needed to add industrial-quality network control, monitoring, and processing to nearly any device. The easy to use development suite contains everything needed to rapidly learn, code, test and deploy an industrial-quality embedded solution.

Want to see just how easy it is to get started? Take a look at the SOMRT1061 Quick Start Guide.

Icon

SOMRT1061 200IR Datasheet 660.21 KB 725 downloads

...
Download

IoT Development Kit Contents

  • 1 NetBurner i.MX RT1061 SOMRT1061 Embedded Platform Hardware (soldered on carrier board)
  • 1 IoT Development Kit Adapter board
  • 1 Quick Start Guide
  • 1 NNDK License Card with Platform Serial Number
  • 1 USB Cable
  • 1 DB9 Serial Cable
  • 1 Blue CAT5 Patch Cable
  • 1 Year of Technical Support, Software and Development Tool Updates

Ready to build products? Take a look at the standalone SOMRT1061 NetBurner platform hardware and volume pricing.

More on the i.MX RT1061 CPU used in this NetBurner Embedded Development Kit can be found here:

Product Specific Posts



Specifications

Performance and Memory
Processor Family

ARM Cortex-M7

Processor Model

NXP i.MX RT1061

Clock Speed

528 MHz

Flash

8 MB

SDRAM

32 MB

SRAM

1 MB
Device Connectivity
Analog to Digital (ADC) Channels

8 (12-bit, 2 ADCs)

CAN

3 (CAN-FD)

Ethernet

Two 10/100 Mbps

External Address Bus

12 bit, 28 bit

External Data Bus

16 bit, 8 bit

External IRQ

Any GPIO

Flash Card Support (SDHC/SPI)

On Board

Flex IO

3 (I2C, SPI, UART, I2S, Camera I/F, parallel bus and much more)

GPIO

67

I2C

3

Quad SPI (QSPI)

2

RS-232

Yes

SPI

3

Timer I/O

6 inputs / 6 outputs / 1 external clock input

UART

7

USB Controllers

2

USB Ports

3
Additional Peripherals
Audio Interfaces (SAI)

3 (S/PDIF supporting I2S, TDM, codec/DSP, and GPIO)

Floating Point Unit (FPU)

Yes

General Purpose Timer Channels

8 (32-bit, 2 GPTs, 4 channels each)

MicroSD Connector

Yes

No. RJ-45 (Ethernet Jacks)

Dual

Periodical Interrupt Timer Channels

4 (32-bit)

Pulse Width Modulator (PWM) Channels

32 (16-bit, 4 Flex PWMs, 8 channels each)

Quadrature Encoder/Decoder

4

Quad Timer Channels

12 (16-bit, 3 QTimers, 4 channels each, chainable)

Temperature Sensor

1

True Random Number Generator (TRNG)

Yes
Module Properties
Dimensions

1.00" x 1.00" (inches) (Module Only), 5.3" x 5.3" (inches)

DC Input Voltage

5-24V @ 2W max, 3.3V @ 150mA typical, 330mA max (Module Only)

Temperature Range

Industrial (-40°C to 85°C)

Brand

NetBurner

Module Connector

88 pin, 1.0mm pitch, 1.0"x1.0", castellated PCB
Weight 2 lbs

Documents and Downloads

SOMRT1061 Documents

Icon

Secure Serial Factory App User's Manual 0.00 KB 15379 downloads

...
Download

Development Kit

SOMRT1061 Quick Start Guide
NetBurner 3.0 Online Documentation

No downloads found!

    Deployment Tools

    No downloads found!

      Application Notes

      No downloads found!

        Reviews

        There are no reviews yet.
