ARM® Embedded System-on-Module MODM7AE70

MODM7AE70 100 ARM powered IoT System on Module with Ethernet Jack

$89.00

NetBurner’s ARM® Cortex®-powered Ethernet System-on-Module is an IoT device platform containing everything needed to add secure, industrial-quality IoT, network control and monitoring to nearly any smart application or product design.

New to  this embedded system-on-module? Get started with a development kit!

Upgrading from one of our MOD52XX modules? See our pinout comparison to ensure an easy product transition.

Not seeing exactly what you need with this module, or are you looking for a custom solution? Check out our OEM Design Services and let us design the perfect part for you.

SKU: N/A Category: Tags: , , , , , , , , , , , , , ,
All of our hardware is RoHS compliant, covered by our
1 Year Warranty and Made in the USA.

Description

Icon

MODM7AE70 Datasheet 7299 downloads

The ARM® Cortex®-powered NetBurner Ethernet System-on-Module is a device containing... (Read More)
Download

ARM® Embedded System-on-Module MODM7AE70

Need a high-performing and reliable ARM® embedded IoT device for secure automation and industrial IoT applications? For a very low price point, this ARM® Cortex-M7 embedded system-on-module (SOM) solves the problem of securely network-enabling devices with 10/100 Ethernet, including those requiring SSL/TLS, machine-to-machine (M2M) protocols, digital, analog and serial control, and much more. The product can also be used as an edge node microcontroller, edge processor or IoT gateway.

Microchip®/Atmel® ARM® processors are combined with NetBurner’s acclaimed reliability and ease-of-use to get you a solution you can depend on.

Try out our IoT development kit! The best way to get started.

Read the ARM® Embedded System-on-Module MODM7AE70 Product Release / Press Release at Newswire.com

Product Posts

Specifications

Performance and Memory
Processor Family

ARM

Clock Speed

300 MHz

Flash

2 MB

SDRAM

8 MB

SRAM

384 Kb
Device Connectivity
Ethernet

10/100 Mbps

UART

5

USART

2

SPI

4

Quad SPI (QSPI)

1

Analog to Digital (ADC)

11

CAN

2

Digital to Analog (DAC)

1

External Data Bus

16 bit

GPIO

53

I2C

3

Timer I/O

9

SD/MMC Flash Card Ready

Yes

RS-422/485

Requires external transceiver
Additional Peripherals
Floating Point Unit (FPU)

Yes

High-speed Multimedia Card Interface (HSMCI)

Yes

Image Sensor Interface (ISI)

1

Pulse Width Modulator (PWM)

17

Watchdog Timer

1
Physical Properties
Dimensions

2.60" x 2.00" (inches)
Module Properties
DC Input Voltage

3.3V @ 100mA typical, 250mA max

Temperature Range

Industrial (-40°C to 85°C)

Brand

NetBurner
More
MODM7AE70 Versions Available

MODM7AE70-100IR (RJ-45), MODM7AE70-200IR (10-pin Header)
Weight .1 lbs

Documents and Downloads

MODM7AE70 Online Guides

MODM7AE70 Quickstart Guide

NNDK 3.X Quickstart Guide

NNDK 2.X Quickstart Guide

NNDK 3.X Documentation

MODM7AE70 Documents

Icon

MODM7AE70 Mechanical Diagram (100 Version) 2060 downloads

This document is the mechanical diagram for the MODM7AE70-100IR. ... (Read More)
Download
Icon

MODM7AE70 Datasheet 7299 downloads

The ARM® Cortex®-powered NetBurner Ethernet System-on-Module is a device containing... (Read More)
Download
Icon

Schematic: MOD-DEV-70 6913 downloads

... (Read More)
Download

    Development Kit

    Icon

    MODM7AE70 Mechanical Diagram (100 Version) 2060 downloads

    This document is the mechanical diagram for the MODM7AE70-100IR. ... (Read More)
    Download
    Icon

    ARM Cortex-M7 Processor Technical Reference Manual 5615 downloads

    ... (Read More)
    Download
    Icon

    ARMv7-M Architecture Reference Manual 2908 downloads

    ... (Read More)
    Download
    Icon

    SAM E70/S70/V70/V71 DataSheet 2225 downloads

    ... (Read More)
    Download
    Icon

    SAM E70/S70/V70/V71 Reference Manual 2584 downloads

    ... (Read More)
    Download
    Icon

    SAM E70/S70/V70/V71 Errata 1414 downloads

    ... (Read More)
    Download
    Icon

    Comparing RTOS to Infinite Loop Designs 24967 downloads

    ... (Read More)
    Download

      Deployment Tools

      Icon

      MTTTY Serial Terminal 29879 downloads

      ... (Read More)
      Download
      Icon

      IP Setup 57199 downloads

      IPSetup is a Windows program used to configure NetBurner hardware through a network... (Read More)
      Download
      Icon

      Virtual COMM Port Driver (Windows 7 - 10) 104124 downloads

      Download the popular Virtual COMM Port Driver for use with NetBurner modules. Add... (Read More)
      Download

        Application Notes

        Icon

        What Female Header is Used to Accept a NetBurner Module on the Development Carrier Board? 6366 downloads

        ... (Read More)
        Download
